Top paper exit/front paper exit design
Standard GB18030 large font library, multiple fonts optional
Supports QRCODE QR code and various one-dimensional barcode printing
Support multi-interface time-sharing printing
Supports vertical placement and front paper ejection printing
Supports buzzer paper shortage alarm and incoming order prompt
| Model | 58IIK |
| Printing | |
| Printing method | Direct thermal |
| Paper width | 57.5±0.5mm |
| Print width | 48 mm |
| Column capacity | 384 dots/line(adjustable by command) |
| Printing speed | 90mm/s |
| Interface | USB/USB+Serial / USB+Bluetooth/ USB+Bluetooth+Serial / USB+Bluetooth+Serial+WIFI |
| Line spacing | 3.75mm (Adjustable by commands) |
| Fonts Symbologies | |
| Character size | Font A: 12x24;Font B: 9x17;CHN: 24*24 |
| Characters /Line | Font A: 32 chars;Font B: 42 chars;CHN: 16 Character Sets |
| 1D Barcode | UPC-A / UPC-E / JAN13(EAN13) / JAN8(EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128 |
| 2D Barcode | QR code |
| Input buffer | 32 Kbytes |
| NV Flash | 64 Kbytes |
| Power | |
| Power adaptor | AC 110V/220V, 50~60Hz; DC 12V/2.6A |
| Power source | DC 12V/2.6A |
| Cash drawer output | DC 12V/1A |
| Physical characteristics | |
| Weight | 0.498 KG |
| Dimensions | 121.8*110*114.6mm(D*W*H) |
| Environmental Requirements | |
| Work environment | Temperature (0～45℃) humidity(10～80%) |
| Storage environment | Temperature(-10～60℃) humidity(10～90%) |
| Reliability | |
| Printer head life | 50KM |
| Software | |
| Emulation | ESC/POS |
| Driver | Windows/JPOS/Linux/Android/Mac |
| Utility | Windows & Linux test Utility |
| SDK | IOS/ Android/ Windows |
