Applicable to ratail/payment/catering/medical and other fields
| POS2300W Technical Parameter | |||||||
| Model | POS2300W | ||||||
| Item | Wired 2D Barcode Scanner | ||||||
| Physical Parameter | |||||||
| Material | ABS+PC | ||||||
| Power Supply | DC 5V ±5% | ||||||
| Electric Current | 200mA（working）；127mA（standby）；270mA（maximum） 【average current】 |
||||||
| Power Consumption | 1.00W（working）；0.63W（standby）；1.35W（maximum） 【Average power consumption】 |
||||||
| Weight | 145.0g±5g（Without cable） | ||||||
| Size | L*W*H：164.5 * 91.5 * 68.0（unit：mm） | ||||||
| Color | Black | ||||||
| Performance Parameter | |||||||
| Interface | USB | ||||||
| System Supported | Linux，Android，Windows XP、7、8、10，MAC | ||||||
| Language Supported | English；Belgian ；Finnish；French；German；Italian；Swedish；British；Danish；norwegian；Spanish ；Portuguese ；Turkish Q；Turkish F；Japanese ；Russian；Czech ；Thai；Ukrainian ； Brazilian ； Greek；Hungarian ；Dutch；Polish；Romanian； Slovak； (Virtual keyboard support) |
||||||
| Sensor | 1280*800 Global CMOS sensor | ||||||
| Light Source | Red led aiming + white led lighting | ||||||
| Processor | 32-bit ARM MCU + DSP | ||||||
| Motion Tolerance | Code128： 75cm/sec QR：80cm/sec |
||||||
| Resolution | ≥3mil | ||||||
| Bit Error Rate | 1/5000000 | ||||||
| Reading mode | Image | ||||||
| Trigger Mode | Manual ；Continuous scanning;Auto-sensing | ||||||
| Prompt Mode | Buzzer, Indicator Light（LED） | ||||||
| Print Contrast | ≥25% | ||||||
| Scanning Angle | Pitch±55°，Yew±55°，Roll 360° | ||||||
| Decoding Capability |
1D | ◎Interleaved 2 of 5 ◎ITF-6 ◎ITF-14 ◎ISBN ◎Code 11 ◎UCC/EAN-128 ◎GS1 Databar ◎Matrix 2 of 5 ◎Industrial 2 of 5 ◎Code 128 ◎EAN-13 ◎EAN-8 ◎Code 39 ◎UPC-A ◎UPC-E ◎Codabar ◎Standard 2 of 5 ◎Plessey ◎MSI-Plessey ◎Code 93 ◎GS1 composite code |
|||||
| 2D | ◎PDF417 ◎Data Matrix ◎QR Code ◎HanXin ◎AZTEC ◎Maxicode | ||||||
| Scanning depth | QR 14.17mil 8bytles：1cm - 20cm PDF417 7.5mil：1cm - 9cm EAN13 10mil: 3cm - 30cm |
||||||
| Environment Parameter | |||||||
| IP Grade | IP52 | ||||||
| Operating Temp. | 0 to 60℃ / 32 to 122℉ | ||||||
| Storage Temp. | 0 to 60℃ / 32 to 122℉ | ||||||
| Operating Humidity | 20% to 85%（No Condensation） | ||||||
| Storage Humidity | 20% to 85%（No Condensation） | ||||||
| ESD Protection | 15KV air discharge | ||||||
| Shock Resistance | 1.5m free fall on concrete surface | ||||||
| Environmental light | 0→100000Lux | ||||||
| Note: This parameter is subject to change without prior notice. | |||||||
