● Easy paper loading, waterproof, oil proof, dustproof design
● Support print prompt and error alarm
● Support GB18030 simplified Chinese, traditional Chinese, buyer optional languages
● Printing images and characters with high speed, the best printing quality and reliable performance
| Printing | |
| Printing method | Direct thermal |
| Print width | 72mm/ 76mm/ 80mm/ 64mm/ 48mm/ 52mm |
| Column capacity | 576 dots/line or 512 dots/line |
| Printing speed | 300mm/s Max. |
| Interface | USB+Serial+Lan/USB+Parallel （Optional : WIFI/Bluetooth) |
| Printing paper | 79.5±0.5mm×φ80mm |
| Line spacing | 3.75mm (Adjustable by commands) |
| Column number | 80mm paper: Font A - 42 columns or 48 columns/Font B - 56 columns or 64 columns/ |
| Chinese,traditional Chinese - 21 columns or 24 columns | |
| Character size | ANK，Font A：1.5×3.0mm（12×24 dots） Font B：1.1×2.1mm（9×17 dots） Chinese,traditional Chinese:3.0×3.0mm（24×24 dots） |
| Cutter | |
| Auto cutter | Partial |
| Barcode Character | |
| Extension character | PC347（Standard Europe）、Katakana、PC850（Multilingual）、PC860（Portuguese）、PC863（Canadian-French）、PC865（Nordic）、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866（Cyrillic#2）、PC852（Latin2）、PC858、IranII、Latvian、Arabic、PT151（1251） |
| sheet | |
| Barcode types | UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/CODABAR/CODE93/CODE128 |
| 2D code | QR Code / PDF417 |
| Buffer | |
| Input buffer | 2048k bytes |
| NV Flash | 256k bytes |
| Power | |
| Power adaptor | Input：AC 110V/220V, 50～60Hz |
| Printer input | DC 24V/2.5A |
| Cash drawer | DC 24V/1A |
| Physical characteristics | |
| Weight | 1.70KG |
| Dimensions | 190×145×150mm (D×W×H) |
| Environmental Requirements | |
| Work environment | Temperature (0～45) humidity(10～80%) |
| Storage environment | Emperature(-10～60℃) humidity(10～80%) |
| Reliability | |
| Cutter life | 1.5 million cuts |
| Printer head life | 150 KM |
190*145*150MM
