● Easy paper loading, waterproof, oil proof, dust proof design
● Compatible with EPSON ESC/POS
● Support print prompt and error alarm
● Printing image and characters with high speed, the best printing quality and reliable performance
● Support 256K bytes NV logo download store and print
● Support GB18030 simplified Chinese, traditional Chinese, buyer's language
| Printing | |
| Printing method | Direct thermal |
| Printer width | 80mm |
| Column capacity | 576 dots/line 512 dots/line |
| Printing speed | 300mm/s |
| Interface | USB+Serial+Lan/USB+WIFI |
| Printing paper | 79.5±0.5mm×φ80mm |
| Line spacing | 3.75mm (Adjustable by commands) |
| Print command | ESC/POS |
| Column number | 80mm paper: Font A - 42 columns or 48 columns/ Font B - 56 columns or 64 columns/ Chinese, traditional Chinese - 21 columns or 24 columns |
| Character size | ANK，Font A：1.5×3.0mm（12×24 dots）Font B：1.1×2.1mm（9×17 dots） Chinese,traditional Chinese:3.0×3.0mm（24×24 dots） |
| Cutter | |
| Auto cutter | Partial |
| Barcode Character | |
| Extension character sheet | PC347（Standard Europe）、Katakana、 PC850（Multilingual）、PC860（Portuguese）、 PC863（Canadian-French）、PC865（Nordic）、 West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866（Cyrillic#2）、PC852（Latin2）、PC858、IranII、Latvian、Arabic、PT151（1251） |
| 1D code | UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/CODABAR/CODE93/CODE128 |
| 2D code | QR Code / PDF417 |
| Buffer | |
| Input buffer | 2048Kbytes |
| NV Flash | 256k bytes |
| Power | |
| Power adaptor | Input：AC 100V/240V, 50～60Hz |
| Power source | Output：DC 24V/2.5A |
| Cash drawer output | DC 24V/1A |
| Physical characteristics | |
| Weight | 1.66 KG |
| Dimensions | 193.3(D)*145(W)*144(H)mm |
| Environmental Requirements | |
| Work environment | Temperature (0～45℃) humidity(10～80%)（non-condensing） |
| Storage environment | Temperature(-10～60℃) humidity(10～90%) |
| Reliability | |
| Cutter life | 1.5 million cuts |
| Printer head life | 150KM |
| Driver | |
| Drivers | Win 9X/Win 2000/Win 2003/Win XP/Win 7/Win 8/Win 10/Linux |
193.3*145*144mm
